WNMG080412-TM TC75
| Specification and model | D | L1 | D1 | Ds | Blade size range | Screw | Wrench |
|---|---|---|---|---|---|---|---|
| JCD C20-100-10D | 10 | 100 | 24 | 20 | □CD-10.0-10.9 | CM2.2*9 | T6 |
| JCD C20-110-10D | 11 | 110 | 24 | 20 | □CD-11.0-11.9 | ||
| JCD C20-120-10D | 12 | 120 | 24 | 20 | □CD-12.0-12.9 | ||
| JCD C20-130-10D | 13 | 130 | 24 | 20 | □CD-13.0-13.9 | CM2.5*12 | T8 |
| JCD C20-140-10D | 14 | 140 | 24 | 20 | □CD-14.0-14.9 | ||
| JCD C20-150-10D | 15 | 150 | 24 | 20 | □CD-15.0-15.9 | ||
| JCD C20-160-10D | 16 | 160 | 24 | 20 | □CD-16.0-16.9 | CM2.5*14.2 | T8 |
| JCD C20-170-10D | 17 | 170 | 24 | 20 | □CD-17.0-17.9 | ||
| JCD C20-180-10D | 18 | 180 | 24 | 20 | □CD-18.0-18.9 | CM3*16.5 | T10 |
| JCD C25-190-10D | 19 | 190 | 29 | 25 | □CD-19.0-19.9 | ||
| JCD C25-200-10D | 20 | 200 | 29 | 25 | □CD-20.0-20.9 | ||
| JCD C25-210-10D | 21 | 210 | 29 | 25 | □CD-21.0-21.9 | CM3*19.7 | T10 |
| JCD C25-220-10D | 22 | 220 | 29 | 25 | □CD-22.0-22.9 | ||
| JCD C25-230-10D | 23 | 230 | 29 | 25 | □CD-23.0-23.9 | ||
| JCD C32-240-10D | 24 | 240 | 39 | 32 | □CD-24.0-24.9 | CM3.5*22.5 | T15 |
| JCD C32-250-10D | 25 | 250 | 39 | 32 | □CD-25.0-25.9 | ||
| JCD C32-260-10D | 26 | 260 | 39 | 32 | □CD-26.0-26.9 | CM3.5*24 | T15 |
| JCD C32-270-10D | 27 | 270 | 39 | 32 | □CD-27.0-27.9 | ||
| JCD C32-280-10D | 28 | 280 | 39 | 32 | □CD-28.0-28.9 | CM4*25.5 | T15 |
| JCD C32-290-10D | 29 | 290 | 39 | 32 | □CD-29.0-29.9 | ||
| JCD C32-300-10D | 30 | 300 | 39 | 32 | □CD-30.0-30.9 | CM5*27.5 | T20 |
| JCD C32-310-10D | 31 | 310 | 39 | 32 | □CD-31.0-32.0 |
